Professional Diesel Concrete Pump 1400mm Feeding Height 500L Hopper Volume

Product introduction HBT100SR18186C

ZOOMWOLF concrete pumpHBT100SR18186C

This is a high output pressure(18MPa) concrete pump,powered by diesel engine.

Technical performance:

Output capacity(m³/h):57(high pres.)/103(low pres.)

Output pressure(MPa):18(high pres.)/10(low pres.)

Distribution Valve:S valve

Rated power of BF6M1013 diesel engine(kW):186

Oil pres.of the pumping system(MPa):32

Hydraulic system circle form:Twin-pump and -circuit open system.

Oil tank volume(L):500

Overall dimension L×W×H(mm):6460×1962×2620

Total mass(kg):6685

About the easy to wear parts of concrete pump

Concrete pump is through the pressure delivery of concrete, some parts and components directly with concrete or slurry leakage particles contact and friction or corrosion and inevitable damage. The extent of their damage depends on many factors, such as the material of the parts themselves, the stiffness of the concrete aggregates, pumping pressure and pumping speed.
In the composition of the concrete pump, the following parts are easy to wear, should be an appropriate amount of spare parts inventory to meet the needs of timely replacement: eye-glass plate, cutting ring, S tube, transition sleeve, mixing shaft, mixing blade, shaft end seals, conveying pipe, hose, rubber ring, rubber spring, concrete piston, etc..


18-fig.(1)Examples of the easy to wear parts

Changsha Zoomwolf machinery CO.,LTD is a high-tech enterprise,which is situated in Changsha,Hunan province,China,known as the capital of engineering machinery. We are engaged in research, development,manufacturing,sale and service of construction machinery and spare parts. We mainly manufacture concrete placing booms,trailer-mounted concrete pumps and concrete pumping-units. Our products technical performances keeps Zoomwolf preferred in the industry.

Zoomwolf president and General Manager Mr. Fulicai possesses over 20 years experience in construction industry. He has in-depth experience of managing,manufacturing,quality control,technology,marketing and after service etc. He is a great visionary with lot of enthusiasm for taking Zoomwolf to greater heights.

Zoomwolf is strengthened with experienced professionals in the construction industry. Zoomwolf products are manufactured using the best international components and techniques. Full process material pre-treatment and complete set of fine machining equipment ensures the quality of Zoomwolf products.

Zoomwolf products have sold to various regions of China very well and have been exported to Middle-East,Southeast Asia,South America and Africa etc. We have a team of international service engineers to provide excellent after-sale service and technical support each oversea client.

Zoomwolf will strive to provide quality products and professional service for Customers. Think Globally,Act Locally. Teamwork achieves greats. We spare no efforts to be the leader in the market.
